Vibratory Screening Machine

Product description

The rotary vibrating screen is a screening device that uses a vertical motor to drive the upper and lower eccentric weights, causing the screen surface to generate a three-dimensional compound vibration of horizontal, vertical and inclined. The materials on the screen surface diffuse in a spiral shape, achieving precise classification of different particle sizes. It features high screening accuracy, large processing capacity, compact structure and good sealing performance. Moreover, by adjusting the vibration parameters, it can be adapted to various materials such as granules, powders and slurries. It is widely used in screening and filtration operations in industries such as chemical engineering, food, medicine and mining.

Working principle
The rotary vibrating screen is a screening equipment that uses a vertical motor as the excitation source. Through the rotation of the eccentric weights at the upper and lower ends of the motor, the screen surface generates three-dimensional compound vibrations in the horizontal, vertical and inclined directions, driving the materials to diffuse in a spiral motion from the center to the periphery, thereby achieving precise classification of materials of different particle sizes. It features high screening accuracy, large processing capacity, compact structure and flexible adjustment. It is widely used in the screening and filtration of particles, powders and slurries in industries such as chemical engineering, food, medicine and mining. The vibration parameters can be adjusted according to the characteristics of the materials (such as particle size, moisture and corrosiveness) to meet diverse production needs.

Features & Benefits

1. Unique vibration: Three-dimensional compound vibration, material spiral diffusion screening.
2. High precision and efficiency: The screening accuracy is over 95%, and the processing capacity is 30%-50% higher than that of traditional screens.
3. Adjustable parameters: The Angle of the weight hammer, rotational speed, etc. can be adjusted to adapt to different materials.
4. Compact structure: Small footprint, sealed design to prevent dust, suitable for clean environments.
5. Easy maintenance: The screen mesh can be quickly disassembled, the components are easy to inspect and repair, and it is highly durable.
6. Diverse materials: Carbon steel and 304/316L stainless steel are available for selection, which are corrosion-resistant and wear-resistant.
7. Wide application: Suitable for various forms of materials such as granules, powders, and slurries.
8. Flexible customization: Supports customization for special working conditions such as explosion-proof and high-temperature resistance.
