Vibratory Screening Machine

Product description

The rotary vibrating screen is an efficient and multi-purpose screening equipment that achieves rapid material classification through its unique three-dimensional vibration mode. It adopts a fully enclosed structure, effectively preventing dust from spilling out during operation and meeting the requirements of clean production. The equipment has high screening accuracy and large processing capacity. It can adapt to the screening needs of different materials through simple adjustment and supports multi-layer synchronous classification. Its structural design is easy to replace the screen mesh quickly and clean thoroughly, operates smoothly and reliably, and is widely used in industries such as food, chemical, and metallurgy for the fine screening and filtration of particles, powders, and slurries.

Working principle
The working principle of the rotary vibrating screen is based on its core vibration source - the vertical vibration motor. The eccentric blocks installed at both ends of the motor generate excitation force when rotating at high speed. By adjusting the relative angle of the two eccentric blocks, a complex three-dimensional vibration trajectory can be formed. This combined motion causes the materials on the screen to undergo continuous lifting, diffusion, and spiral forward movement. During this process, the materials automatically separate according to particle size, with fine particles quickly passing through the screen and coarse particles being transported to the discharge port, thereby achieving continuous and efficient screening and classification.

Features & Benefits

1.High efficiency and high precision
The three-dimensional vibration ensures that the materials are quickly separated and screened, with a large processing volume per unit time and accurate classification.
2. Sealed and environmentally friendly
The fully enclosed design effectively controls the leakage of dust and liquids, meeting the requirements of clean production.
3. Easy adjustment
By adjusting the eccentric block, it can adapt to different material properties and screening fineness requirements.
4. Multi-layer synchronous screening
Supports single-machine multi-layer configuration, enabling multiple-stage separation in one operation, thus saving space and process.
5. Easy maintenance
The screen can be replaced quickly, and the structure is easy to clean, significantly reducing downtime.
6. Durability and Low Energy Consumption
The sturdy structure combined with high-quality materials ensures smooth and reliable operation, with long lifespan and low energy consumption.

Product parameter

Production line diagram

1. Vacuum feeding into the mixer, automated, dust-free
2. The mixed materials directly enter the sieve machine for screening
