​Z Type Bucket Elevator

Product description

The Z-shaped elevator is a material conveying equipment that combines high efficiency and flexibility. With its unique Z-shaped structure, it ingeniously utilizes vertical space to lift and transfer materials, significantly saving floor space within a limited area. Meanwhile, the fully enclosed design endows it with excellent dust-proof performance, meeting environmental protection standards, and it is widely used in industries such as food and chemical engineering that have high requirements for dust control. Moreover, it supports customized design, allowing for flexible adjustment of parameters based on the characteristics of different materials, conveying capacity and site conditions. It is easy to maintain, safe and reliable, and can meet diverse production demands.

Working principle

The Z-shaped lifting conveyor is composed of a drive unit, a tensioning device, a conveying chain (or belt), a hopper and a frame. When it is in operation, the motor drives the main shaft through the reducer, and then drives the conveying chain (or belt) to rotate through the sprocket (or pulley). The hopper fixed on it is loaded with materials when passing through the feeding port, and then rises along the Z-shaped track to complete the vertical lifting. When it reaches the discharge port, Materials are dumped by means of track changes or unloading devices. The empty hopper after unloading continues to run in a cycle, while the tensioning device adjusts the tension of the chain (or belt) throughout the process to ensure stable and reliable conveying.

Product characteristics

1. Compact structure: The Z-shaped structure combines horizontal and vertical conveying, saving floor space and being suitable for narrow Spaces.
2. Efficient conveying: Customizable hoppers, speeds and power are available to meet the conveying requirements of different materials and production scales.
3. Stable operation: The chain or belt drive is smooth, reducing material spillage and damage, and ensuring the conveying quality.
4. Excellent sealing performance: Fully enclosed design effectively prevents dust from flying and material leakage, meeting environmental protection requirements.
5. Easy maintenance: The structure is simple, and the components are easy to disassemble and replace, reducing maintenance costs and extending the service life of the equipment.
6. Flexible inlet and outlet: Supports the setting of multiple feed ports and discharge ports to achieve single-point or multi-point automatic supply and discharge.
7. Strong adaptability: Suitable for various forms of materials, hoppers and conveying components can be selected as needed.
8. Safety and reliability: Equipped with safety devices, it operates with low noise to ensure the safety of both the operator and the machine.
