Vibratory Screening Machine For Improved Production Efficiency And Versatility

Basic Information
Place of Origin: CHINA
Brand Name: EVERSUN
Certification: ISO,CE
Model Number: ZPS
Minimum Order Quantity: 1set
Price: negotiable
Packaging Details: Standard export wooden cases
Delivery Time: within 7-15 work days
Payment Terms: L/C,D/A,D/P,T/T,MoneyGram,Western Union
Supply Ability: 5000set/year
Detail Information
Function: Screening\separation\sorting\sieving Keyword: Industrial Sieve
Key Words: Vibrating Screen Maintenance: Easy And Low Cost
Material: Stainless Steel Screening Size Range: From 1mm To 100mm
Warranty: 1 Year Mesh Size: 2-500mesh
Diameter: 400-2000mm Screening Motion: Circular, Elliptical, Or Linear
Installation Method: Floor-mounted Or Suspended Special Features: Dust-tight And Low Noise Operation
Customized: Support

Product Description

Industrial screening machine

Product description
The straight-through vibrating screen is an efficient and lightweight screening device. It is driven by a vibrating motor and uses the exciting force generated by the vibration source to achieve material screening.
It has a compact structure and is composed of a sieve box, vibrating motors, a screen and so on. Its features include high screening efficiency, low noise and easy disassembly and assembly.
It is applicable to industries such as food, chemical engineering, and pharmaceuticals. It can remove impurities and classify granular and powdered materials. It can quickly discharge the materials on the screen and those under the screen. It is especially suitable for screening with high output and low impurities.

Working principle
The working principle of the straight-through screen is as follows: When the double-axis vibration motor operates, the two eccentric blocks rotate at high speed, generating directional excitation force, which is transmitted to the screen box to cause high-frequency and small-amplitude linear vibration. Fine particles pass through the sieve holes and become the screen discharge, which is discharged directly through the aggregate chamber; coarse particles move forward along the slightly inclined sieve surface and are discharged from the sieve top discharge outlet, thereby efficiently completing the material screening and separation.

Product Features

1. High screening efficiency: High-frequency and low-amplitude vibration prevents blockage, and fine particles can be screened through quickly. The combination of high precision and efficiency is outstanding.
2. Fast discharge speed: The direct discharge structure allows for direct discharge of materials from the top or bottom of the screen, suitable for high-yield continuous processing.
3. Easy maintenance: Simple structure, few components, quick disassembly of the screen, and changing the screen and cleaning do not require complex operations.
4. Strong adaptability: Replaceable screen mesh, meeting the screening needs of various industries such as food and medicine.
5. Low noise: Optimized vibration motor + shock absorption design, stable operation with low noise, environmentally friendly.
6. Space-saving: Compact size and high integration, easy to be integrated into the production line, saving factory floor space.


Product parameter

Model Power(kw) Sieving diameter(mm) Dimension(mm)
BZP-600 0.12 520 740*600*560
BZP-800 0.18 720 1010*800*600
BZP-1000 0.18 890 1200*970*640
BZP-1200 0.25 1090 1430*1700*700
BZP-1500 0.25 1390 1780*1470*760
Machine can be customized based on your need














Production line diagram
Vibratory Screening Machine For Improved Production Efficiency And Versatility 0

Detail display
Vibratory Screening Machine For Improved Production Efficiency And Versatility 1
Vibratory Screening Machine For Improved Production Efficiency And Versatility 2

Application
Vibratory Screening Machine For Improved Production Efficiency And Versatility 3

Packaging & Shipping
Vibratory Screening Machine For Improved Production Efficiency And Versatility 4

Why Choose us
Vibratory Screening Machine For Improved Production Efficiency And Versatility 5
Vibratory Screening Machine For Improved Production Efficiency And Versatility 6
Vibratory Screening Machine For Improved Production Efficiency And Versatility 7
Vibratory Screening Machine For Improved Production Efficiency And Versatility 8
