Bulk Bag Discharger

Product description

Ton bale feeding station is mainly composed of support, ton bale lifting device, bag breaking device, screening device, etc. It can efficiently discharge and feed the materials in tons of bags, which is suitable for many industries such as chemical industry, food industry and building materials industry. Through mechanized operation, it can greatly improve the feeding efficiency, reduce the manual labor intensity, and effectively prevent material leakage and dust flying, ensure the cleanliness of the production environment, improve the automation level and safety of the production process, and is an important equipment to achieve high efficiency, environmental protection and accurate feeding of materials.

Working principle

The working principle of the ton bag feeding station is as follows: First, the ton bag is lifted and moved to the designated position by the lifting device, and then the bag breaking device is used to break the bag and make the material flow out. In the process of material falling, the screening device will screen it and intercept the debris that does not meet the requirements. At the same time, the dust removal device starts to collect dust by pumping air and other ways to prevent environmental pollution. The whole process collaborates with mechanical automation and related devices to achieve efficient, environmentally friendly, accurate feeding and preliminary treatment of tons of bale materials.

Product features

Efficient operation: It can quickly complete the unloading and feeding of tons of bale materials, greatly improving production efficiency and reducing the time cost of manual handling and feeding.
Save manpower: realize mechanization operation, reduce labor intensity, reduce manpower input, and reduce the labor cost of enterprises.
Good environmental performance: equipped with dust removal device, effectively control dust flying, reduce dust pollution, improve the working environment, in line with environmental requirements.
Accurate feeding: It can accurately control the feeding amount and feeding speed, ensure the accuracy of material delivery, and help improve the stability of product quality.
Safe and reliable: with a variety of safety protection devices, such as guardrail, emergency stop button, etc., to reduce the safety risk of operators and ensure production safety.
Widely used: suitable for chemical, food, building materials, plastics and other industries of different types of materials, strong versatility, to meet a variety of production needs.

Bag size application	1000x1000x1600 mm
Power Source	AC 380 v ± 5%50 Hz
Air source pressure	≥ 0.6MPa
Air consumption	≤ 0.6 m ³/min
wind volume for dust-removal	800-2500m3/h
Environment humidity	-100C-400C
Cutting capacity	10-20 bags/h (manual)

























Product details

Product display



Line application





Product application



Application scope

The bulk bag unloading machine is mainly used in fields such as plastics, rubber, food, medicine, and chemicals for unpacking and discharging bags of dry powders and granular materials, such as plastic resins and food additives.
