Bulk Bag Unloader
Product description
The dust-free feeding station is a powerful device for dealing with dust pollution in industrial production, widely used in industries such as pharmaceuticals and food that high requirements for environmental cleanliness. It consists of a feeding area, dust removal system, filter unit, and control system. Through sealed design, strong suction, fine filtration and automatic dust removal mechanism, it effectively collects and purifies the dust generated during feeding, ensuring the cleanliness of the workshop air and creating a clean and safe production for enterprises, and contributing to the high-quality development of the industry.
Working principle
When the dust-free feeding station is in operation, materials enter through the sealed feeding port, preventing the initial escape of dust. Subsequently, the is activated to create a negative pressure within the station, and the powerful suction quickly draws the raised dust into the dust removal pipeline. The dusty air enters the filtration, where it first encounters a coarse filter screen that intercepts large particles, followed by a medium filter screen that filters smaller particles, and finally an efficient filter screen that fine dust. The purified air is then discharged. In addition, the cleaning mechanism regularly clears the accumulated dust on the filter screens, ensuring the continuous and stable operation of equipment and achieving dust-free feeding.
Features & Benefits
1. Efficient dust removal: Equipped with a professional and efficient dust removal system, the powerful suction can quickly collect dust, and the-precision filter screen ensures a dust removal efficiency of over 99%, effectively purifying the workshop air.
2. Tight sealing: The feed port and overall structure special sealing materials and designs, closely adhering to the material containers, eliminating dust overflow from the source and ensuring a clean workshop environment.
3. Fine filtration: Using multi-layer filter screen combination, the coarse, medium, and high-efficiency filter screens filter in sequence, accurately capturing dust from large particles to fine powder, meeting cleanliness requirements.
4. Easy operation: The feed port design complies with ergonomics, with appropriate height and angle, simple and easy-to-understand operation process reducing the labor intensity and learning cost of workers.
5. Wide adaptability: It can flexibly connect with different shapes and specifications of material packaging, whether it isged, barrelled, or bulk materials, it can complete the feeding process smoothly.
6. Simple maintenance: The equipment structure is designed reasonably, and key components such filter screens and fans are easy to disassemble and replace. The dust removal mechanism has a high degree of automation, and the maintenance cost is low.
Product parameter
| Model |
Feeding port diameter |
Power of blower |
Air pressure of blower |
| EDS-600 |
600mm/24inch |
1.5KW |
3Kpa-25m³/m |
| EDS-800 |
800mm/32inch |
1.5KW |
3Kpa-25m³/m |
| EDS-1000 |
1000mm/40inch |
2.2KW |
3.6Kpa-39m³/m |
| EDS-1200 |
1200mm/48inch |
2.2KW |
3.6Kpa-39m³/m
|
Detail display
Application
Packaging & Shipping
Why Choose Us
About us
We have been specializing in the production of Screening and conveying equipment for 13 years. China's vibrating screen industry top three. And we have done matching and OEM for many large companies. Including the world's top vibrating screen manufacturer, Sweco, USA, we have OEM for his China region. And our products are often exported to Australia, Thailand, Indonesia, New Zealand and other countries.
We welcome customers or dealers to visit our factory and will arrange everything for you.Our factory address: West of the industrial and commercial office of Da Zhaoying Town, Xinxiang City, Henan Province.
