High Efficiency Carbon Steel Quartz Sand Separator Rotex Vibrating Screen

Basic Information
Place of Origin: China
Brand Name: EVERSUN
Certification: ISO,CE
Model Number: BPH
Minimum Order Quantity: 1set
Price: negotiable
Packaging Details: Standard export wooden cases
Delivery Time: within 7-15 work days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000sets/year
Detail Information
Amplitude: 75-90mm Screen Deck: 1~5
Capacity: 2-150T/h Screen Size: 12mm To 40 Microns
Feeding Size: <75mm Product Name: Rotex Type Gyratory Sifter
Application: Salt, Sugar, Soda Ash, Sand, Urea, Etc Structural Material: Stainless Steel304/316L, Carbon Steel
High Light:

Carbon Steel Rotex Vibrating Screen


arbon Steel Quartz Sand Separator


High Efficiency Rotex Vibrating Screen

Product Description

Product Description:

High Efficiency Carbon Steel Quartz Sand Separator Rotex Vibrating Screen

The Rotex Vibrating Screen, also known as the Rotex Type Gyratory Sifter, is a high-performance and efficient screening equipment designed for a variety of applications. With its unique gyratory motion, this machine effectively separates materials based on size and shape, making it an essential tool for industries such as food, chemical, mining, Pharmaceuticals, building materials and more.


The Rotex Vibrating Screen offers a customizable screen size of 12mm to 40 microns, making it suitable for a variety of particle sizes. This flexibility allows for accurate and efficient screening of different materials, ensuring a high-quality end product.


Overall, the Rotex Type Gyratory Sifter is a top-of-the-line screening machine that offers high-performance, efficiency, and versatility. With its unique gyratory motion and customizable features, it is the ideal choice for industries looking to improve their screening processes and achieve high-quality end products.

Technical Parameters:



Product Specifications:
Model Screen Deck Capacity (T/h) Power (kW) Weight (kg)
BPH-400 1 2-10 1.5 480
BPH-600 1 10-20 2.2 650
BPH-1000 1 20-50 3.7 920
BPH-1200 1 50-100 5.5 1050
BPH-1500 1 100-150 7.5 1280

Customized models and specifications are also available upon request.

High Efficiency Carbon Steel Quartz Sand Separator Rotex Vibrating Screen 0


The features of Rotex Vibrating Screen


1. The structural design is diversified to meet different needs: there are two forms of completely closed structure and open structure.

2. High utilization rate of screen, good screening effect, does not damage the original structure of the material.

3. Large processing capacity, easy to be used for assembly line production.

4. Simple screen change process, easy to use, balanced operation.

5. No pollution, low noise.


Working principle:

Rotex Vibrating Screen- EVERSUN Gyratory Screening Machine
The working principle of the Rotex Vibrating Screen is mainly achieved by the movement of the deflector, and its motion shape is a uniform circular motion, and the inclination is generally 4-9 degrees. And through the drive box to the screen machine, the material in the feed end for horizontal circular movement, in the length direction gradually become elliptical movement, and finally in the discharge end into an approximate reciprocating linear movement.
After the material enters the screen body through the feed port, under the action of vibration force, it can be more evenly distributed on the screen surface of the plane rotary screen, and the material with smaller particle size under the material layer can quickly pass through the screen, while the larger particle size material moves on the discharge end.
High Efficiency Carbon Steel Quartz Sand Separator Rotex Vibrating Screen 1


Rotex Vibrating Screen - EVERSUN Rotex Type Gyratory Sifter

Rotex Vibrating Screen is widely used in food, chemical, mineral, plastic, recycling and other industries. Typical applications such as: compound fertilizer screening, grain screening, silicon alloy screening, urea screening, diammonium phosphate screening, wood chip screening, soda ash screening, salt salt screening, graphite screening, PVC finished powder screening, silicon carbide screening, abrasive screening, tobacco screening, tea screening, etc. The planar rotary screen is an advanced and efficient screening equipment which replaces the traditional screening machine.

Product Applications:

The Rotex Type Gyratory Sifter is widely used in various industries, including but not limited to:Food and beverage, Chemicals, Pharmaceuticals, Mining and minerals, Plastics, Agriculture, Recycling.


High Efficiency Carbon Steel Quartz Sand Separator Rotex Vibrating Screen 2

Packing and Shipping:

Packaging and Shipping of Rotex Vibrating Screen

The Rotex Vibrating Screen will be carefully packaged to ensure safe delivery to our customers. Below are the details of our packaging and shipping process:

  • The machine will be packed in a sturdy wooden crate to protect it during transportation.
  • All parts and components will be securely fastened to prevent damage during shipping.
  • The crate will be labeled with the product name, model number, and customer information for easy identification.
  • The machine will be shipped via a reliable and reputable shipping company.
  • We offer both air and sea freight options to suit the needs and budget of our customers.
  • Once the machine is shipped, we will provide our customers with a tracking number for them to monitor the delivery status.
High Efficiency Carbon Steel Quartz Sand Separator Rotex Vibrating Screen 3


  • Q: What is the brand name of this product?
  • A: The brand name of this product is EVERSUN.
  • Q: What is the model number of this product?
  • A: The model number of this product is BPH.
  • Q: Where is this product manufactured?
  • A: This product is manufactured in China.
  • Q: Does this product have any certifications?
  • A: Yes, this product is certified with ISO and CE.
  • Q: What type of screening machine is this?
  • A: This is a gyratory screening machine.
