| Place of Origin: | CHINA |
|---|---|
| Brand Name: | EVERSUN |
| Certification: | ISO,CE |
| Model Number: | BPH |
| Minimum Order Quantity: | 1 set |
| Price: | negotiable |
| Packaging Details: | Standard export wooden package |
| Delivery Time: | within 8-15 work days |
| Payment Terms: | T/T, Western Union, MoneyGram, L/C |
| Supply Ability: | 5000SETS/YEAR |
| Name: | Rotex Type Square Gyratory Sifter | Screen Deck: | 1~5 |
|---|---|---|---|
| Advantages: | High Accuracy And Large Output | Appliation: | Spherical, Rope, Columnar, Sheet And Other Materials |
| Structural Material: | Stainless Steel304/316L, Carbon Steel | Sieving Precision: | ≤350 Mesh Or ≥0.028mm |
| High Light: | Rotex Type Square Gyratory Sifter,6mm Gyratory Screening Machine,Tea Leaves Gyratory Sifter |
||
Product introduction
High accuracy 1mm-6mm rotex type square gyratory sifter for Tea leaves
Rotex type square gyratory sifter has the wide range of applications: chemical, food, sugar, ceramide, mining, metallurgy, feed, medicine, building materials, mining, food, paper and other industries of large processing capacity of particles sorting, with excellent screening ability. The output of a single unit can even reach 365 tons/hour. In the specific urea, soda ash, fracturing sand, PVC slice, cork powder, ceramide, tea, refractory materials, tobacco, plastic masterbatch, we have more experience.
The equipment uses plane rotary vibrating screen up and down vibration, there is automatic cleaning equipment under the net, compared with the traditional linear screen, improve the life of the screen, small noise, screening area is large, the efficiency from the original 93~95 to 98.5, good prospects for promotion. Plane rotary urea screening machine is mainly for large urea, soda, quartz sand screening development of a new screening equipment, is also widely used in chemical, grain processing, refractory materials, building materials and other industries of screening operations.
Product parameter
| Model | BPH-0815 | BPH-1021 | BPH-1225 | BPH-1530 | BPH-1836 |
| Screen size(mm) | 800*1500 | 1000*2100 | 1200*2500 | 1500*3000 | 1800*3600 |
| Dip angle of screen | 5-10° | ||||
| Screen area(sq.m) | 1.2 | 2.1 | 3 | 4.5 | 6.4 |
| Stroke of screen | 63.5mm | 63.5mm | 72mm | 72mm | 81mm |
| Motor power | 1.5KW | 2.2KW | 3.7KW | 5.5KW | 7.5KW |
| QTY.of level | 1-3 | ||||
| Rotary frequency | 110-180r/min | ||||
Feature
1. Its motion path combined with circular, ellipse, straight line three motion, screening effect is good;
2. Plane rotation to do linear reciprocating motion, low Angle inclined screen surface, high efficiency and high output;
3. Enhanced frame to ensure more balanced operation of equipment. Hanging structure can also be adopted according to the actual site conditions to meet the needs of customers;
4. Close to the net surface of the plane rotation movement, strip, spherical, sheet, column, easily broken, irregular shape of the screening, other sieve machine can not be compared;
5. The material into the machine, will be quickly diluted, stratified, small particles quickly precipitate, through the net;
6. Long material travel, and fast flow speed;
7. The machine has two types, fully closed and open, the user can choose flexibly according to the specific situation.
How to select a rotex gyratory sifter
Choosing a suitable rotex gyratory sifter is more important than your use of rotex shakers, which is the key to success.
The material characteristics affecting the screening operation are material volume density, stacking Angle, particle shape, material activity, adhesion, hygroscopicity, there is no static electricity, particle surface moisture, temperature, particle size distribution, etc.
Screening materials have special characteristics: such as high temperature, corrosion, high static electricity and so on, high temperature or corrosion can choose better vibrating screen material, such as 316L stainless steel.
