| Place of Origin: | CHINA |
|---|---|
| Brand Name: | EVERSUN MACHINERY |
| Certification: | ISO,CE |
| Model Number: | EYBS |
| Minimum Order Quantity: | 1set |
| Price: | negotiable |
| Packaging Details: | Standard export wooden cases |
| Delivery Time: | within 7-15 work days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000sets/year |
| Material: | Stainless Steel304/316L,Carbon Steel | Capacity: | 50 KG~100 T/H |
|---|---|---|---|
| Operation: | Automatic | Screen Material: | Woven Wire Cloth |
| Noise Level: | Low | Advantage: | Precision Screening And Mass Production |
| Mesh Size: | 2~500 | Application: | Food, Chemical, Pharmacy, Mining,Chemicals, Food And Spices, Plastics, Etc |
| High Light: | Low Noise Tumbler Screening Machine,100 T/H Tumbler Screening Machine,Multi Layer Tumbler Sifting Machine |
||
Product Introduction
The Tumbler Screening Machine is an advanced automatic circular sifting machine designed to separate particles into different sizes via a 2~500 mesh size woven wire cloth. It is specifically designed to be a low noise level rotating screening machine with high efficiency and accuracy. This circular screening machine is perfect for separating bulk material like fine powder, granules, and small particles into different sizes and grades. It is highly efficient for screening and sifting various kinds of materials, including chemical, plastic, grain, and more.
Parameter
| Model | Deck | Equipment diameter | Screen mesh Area(m2) | Frequency (r/min) |
Screen slope (degree) |
Sreen mesh | Amplitude (mm) |
Power (kw) |
| EYBS-600 | 1-5 | 600mm | 0.28 | 220-280 | 0-10 | 20microns to 20 mm |
20-70 | 0.75 |
| EYBS-1000 | 1000mm | 0.66 | 220-280 | 0-10 | 20-70 | 1.5 | ||
| EYBS-1200 | 1200mm | 0.98 | 220-280 | 0-10 | 20-70 | 2.2 | ||
| EYBS-1500 | 1500mm | 1.67 | 220-280 | 0-10 | 20-70 | 3 | ||
| EYBS-1800 | 1-4 | 1800mm | 2.37 | 220-280 | 0-10 | 20-70 | 4 | |
| EYBS-2000 | 2000mm | 2.89 | 220-280 | 0-10 | 20-70 | 4 | ||
| EYBS-2600 | 2600mm | 5.3 | 220-280 | 0-10 | 20-70 | 5.5 | ||
| Machine can be customized based on your need | ||||||||
Applications
The Eversun Machinery Tumbler Screening Machine (Model EYBS) is an innovative screening machine designed for low noise level and high efficiency. It is certified with ISO and CE and is suitable for sifting materials with a capacity ranging from 50 kg to 100 tons per hour. The machine is equipped with a woven wire cloth with mesh size from 2 to 500.
The Eversun Machinery Tumbler Screening Machine is a rotary screen machine, also known as a tumbler sifting machine or tumbling sieve machine. It is designed to screen multiple types of materials, using a combination of horizontal, vertical, and circular motion. It is suitable for both dry and wet screening, and can be used for both large and small particles.
The Eversun Machinery Tumbler Screening Machine is equipped with an adjustable gyratory motion, variable frequency drive, and an adjustable amplitude. It can quickly and accurately sort particles into different sizes and grades. The advanced design of the machine ensures accurate and efficient results with minimal noise level.
The Eversun Machinery Tumbler Screening Machine is an ideal choice for both commercial and industrial applications, as it is highly durable and reliable with low maintenance cost. It is also easy to operate and maintain, making it a cost-effective solution for any sifting needs.
The EVERSUN MACHINERY Tumbler Screening Machine (Model No. EYBS) is a specialized machine designed for precision screening and mass production. It can be used in a variety of industries, including food, chemical, pharmacy, mining, chemicals, food and spices, plastics, etc. It has a mesh size of 2-500, and the number of layers can be up to 5. Its unique tumbling sieve machine design ensures high-efficiency screening and accuracy.
Packing and Shipping
The Tumbler Screening Machine will be packaged in a wooden box with adequate packing materials to ensure the machine is protected during shipment. The box will be labeled with the customer's name, address, and the contents of the box.
The Tumbler Screening Machine will be shipped via a reliable courier service and will include tracking information for the customer to monitor the progress of the shipment.
