Customized Pipe Elevator Cement Auger Conveyor With 133mm 0.75 - 4KW 200L

Basic Information
Place of Origin: China
Brand Name: EVERSUN MACHINERY
Certification: ISO,CE
Model Number: ESC
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Standard export wooden package
Delivery Time: within 7-15 work days
Payment Terms: T/T, Western Union, MoneyGram, L/C
Supply Ability: 5000SETS/YEAR
Detail Information
Name: Auger Conveyor Material: Stainless Steel304/316L
Type: U-shape/tubular/shaftless/double-shaft Motor: General Motor/explosion-proof Motor
Application: Cement, Fly Ash, Lime, Food And Other Angle: 30° ~ 60°
Highlight:

133mm Cement Auger Conveyor

,

4KW Cement Auger Conveyor

,

Cement Auger Pipe Elevator


Product Description

Product introduction


Customized Pipe Elevator Cement Auger Conveyor With Ø133mm, 0.75-4KW, 200L



Auger conveyor is suitable for the feeding of powder, powder and powder materials in chemical, food, agricultural and sideline products and other industries, it is one kind of screw conveyor drive by the motor. It is composed by the screw blade, screw shaft with screw pipe. Screw conveyor is suitable for horizontal or inclined continuous transfering for loose powder or granules from 0-90 degree. The construction material of the conveyor can be made of stainless steel304 or carbon steel or stainless steel 316L, The feed mouth can be customized into round or square feed mouth.



The Auger conveyor produced by EVERSUN not only has the conveying function of a general screw machine, but also has unique advantages in cooling, constant temperature, and corrosion resistance of the conveyed material. According to your different production process requirements, We can design the screw conveyor into different structures.



Product parameter






Model

Conveying tube diameter Power Hopper volume Angle(Degree)
ESC-133 133mm 0.75-4KW 200L or customized



30-60



ESC-159 159mm 0.75-4KW
ESC-219 219mm 1.5-4KW
ESC-273 273mm 2.2-4KW
Please consult us for more models

















Customized Pipe Elevator Cement Auger Conveyor With 133mm 0.75 - 4KW 200L 0

Product features


1. Fast speed: auger conveyor uses spiral feeding;
2. Wide range of applications: both powder and powder materials with certain fluidity can be used;
3. The error caused by the change of material specific gravity and material level can be automatically tracked and corrected;
4. The parts in contact with the material are made of stainless steel, which is easy to clean and prevents cross-contamination;
5. The machine is made of stainless steel except for the motor, reducer, bearing, and electrical switch;
6. It can be moved at will, and can be continuously transported in horizontal, inclined, vertical, and other positions;
7. It has good sealing performance and no dust leakage;
8. Flexible production, tailored according to on-site needs.
9. Screw conveyor offers the option of multiple inlets and outlets.

Customized Pipe Elevator Cement Auger Conveyor With 133mm 0.75 - 4KW 200L 1

Customized Pipe Elevator Cement Auger Conveyor With 133mm 0.75 - 4KW 200L 2



Application


Screw conveyor is widely used in various industries, such as building materials, chemical, electric power, metallurgy, coal, food and other industries, suitable for horizontal or inclined conveying powder, granular and small block materials, such as coal, ash, slag, cement, food, material temperature is less than 200℃. Screw conveyor is not suitable for conveying metamorphic, viscous, easy to caking material.The screw conveyor can be connected with production lines with different raw material transportation systems.



It can be used in conjunction with dust-free feeding stations, mixers, packaging machines, vibrating screens and other machines of various specifications to convey powder, granules, and small solids materials.

Customized Pipe Elevator Cement Auger Conveyor With 133mm 0.75 - 4KW 200L 3
