| Place of Origin: | China |
|---|---|
| Brand Name: | EVERSUN MACHINERY |
| Certification: | ISO,CE |
| Model Number: | 20B/30B/40B/60B |
| Minimum Order Quantity: | 1 set |
| Price: | negotiable |
| Packaging Details: | Standard export wooden box |
| Delivery Time: | 5-8 work days |
| Payment Terms: | T/T, Western Union, MoneyGram, L/C |
| Supply Ability: | 5000 sets/year |
| Name: | Universal Mill | Fineness: | 60-150 Mesh |
|---|---|---|---|
| Dimension: | Customized | Material: | Stainless Steel 304 Or 316L |
| Type: | Grinder | Degree Of Grinding: | Atomizer Mill |
| High Light: | Stainless Steel Universal Mill,Universal Fine Powder Grinding Machine,60 Mesh Fine Powder Grinding Machine |
||
| Model | 20B | 30B | 40B | 60B |
| Output(kg/h) | 20-150 | 100-300 | 160-800 | 500-1500 |
| Input material sizes(mm) | 6 | 10 | 12 | 15 |
| Output fineness(mesh) | 60-150 | 60-120 | 60-150 | 60-150 |
| Motor power(kw) | 4 | 5.5 | 7.5 | 18.5 |
| Main rotating speed(rmp) | 4500 | 3800 | 3400 | 2800 |
| Dimension(mm) | 550*600*1250 | 600*700*1450 | 800*900*1550 | 1000*900*1680 |
| Weight(kg) | 250 | 320 | 550 | 850 |
Working principle
Put the material into the hopper of the machine manually, or automatically convey the material into the hopper with the help of conveying equipment such as a vacuum conveyor, and then through the relatively high-speed operation between the movable toothed plate and the fixed toothed plate, the materials are impacted, rubbed, and collided with each other to be crushed, and then the crushed materials pass through the grinding chamber and are discharged from the discharge port.
The fineness of the universal pulverizer can be adjusted by replacing the screen, so as to achieve the desired fineness.
Application
The universal pulverizer is suitable for pharmaceutical, chemical, metallurgy, food, construction, and other industries. It can process hard and difficult materials, including crushing plastic, copper wire, Chinese herbal medicine, rubber, etc. It can also be used as supporting equipment for the pre-processing process of micro-pulverizers and ultrafine pulverizers.
How to buy your own crusher
We will help you choose grinding forms (turbine crushing, hammer crushing, tooth disc crushing, air cooled crushing, needle rod crushing) according to different characteristics of materials. Please contact us for customized machines.
