Place of Origin: | CHINA |
---|---|
Brand Name: | EVERSUN |
Certification: | ISO,CE |
Model Number: | GZJ |
Minimum Order Quantity: | 1set |
Price: | negotiable |
Packaging Details: | Standard export wooden cases |
Delivery Time: | within 7-15 work days |
Payment Terms: | L/C,D/A,D/P,T/T,MoneyGram,Western Union |
Supply Ability: | 5000set/year |
Packing Range: | 10-50kg | Material: | Stainless Steel |
---|---|---|---|
Application: | Food, Beverage, Pharmaceutical, Chemical, Etc. | Product Type: | Packing Machine |
Key Words: | Jar Can Powder Filling Machine | Warranty: | 1 Year |
Driven Type: | Electric | Automatic Grade: | Automatic,Semi-Automatic |
Function: | Filling,Weighing,Sealing | Condition: | New |
Customed Made: | Yes | Multi-language: | Yes |
Type: | Multi-Function Packaging Machine | Oem Service: | Yes |
Highlight: | semi-automatic powder filling machine,bulk granules filling machine 10-50kg,powder filling machine with warranty |
Product description
The powder filling machine is a packaging equipment specifically designed for the automated quantitative filling of powdered materials. It uses an accurate measurement system to efficiently and uniformly inject the pre-set weight or volume of powdered materials into containers. It can also integrate auxiliary functions such as feeding, sealing, and labeling. It is widely used in industries such as food, medicine, chemical, and building materials, and can significantly improve production efficiency, ensure filling accuracy, reduce material waste, and lower the risk of contamination caused by manual operations. It is a key equipment in modern powder product production lines.
Working principle
The powder filling machine achieves automated production through a closed-loop process of "material supply - measurement control - filling execution - linkage control". The storage bin is fed by the feeding device to the measurement mechanism. According to the characteristics of the materials, it adopts screw, volumetric or weighing measurement methods to precisely control the quantity. After measurement, the material is injected through the filling nozzle, and vibration and blowing air are used to prevent blockage and residue. The equipment integrates all links by the PLC system, allowing adjustment of parameters and featuring alarm and counting functions. It solves the problems of low efficiency, poor accuracy and easy contamination caused by manual operation, and is suitable for powder filling needs in various industries such as food and medicine.
Features & Benefits
1. Precise measurement: Through screw, volume or weighing methods, it can adapt to different powder characteristics and meet both general and pharmaceutical-grade high-precision requirements.
2. Strong automation: The PLC system integrates the entire process, supports continuous production, allows for flexible parameter adjustment, and reduces manual intervention and errors.
3. Wide applicability: Compatible with bottles, bags, cans, etc., equipped with anti-blocking and anti-residue functions, covering multiple industries such as food, medicine, and chemicals.
4. Safe and clean: Reduces manual contact, some models have dust-proof and cross-contamination prevention designs, and comply with hygiene standards.
5. Efficient and stable: Improves production efficiency, reduces material waste, has fault alarm and counting statistics functions, and ensures stable operation.
Product parameter
Metering Mode | Auger filling, Loading cell |
Package Weight | 5kg / 10kg / 15kg / 20kg / 25kg / 50kg or customized |
Materials | SS304 / SS316L / Carbon steel |
Package Accuracy | ±0.2-1%(according to the material) |
Packaging Speed | 2-10bags/min(according to the material) |
Power Supply | 220V,380V,480V or customized |
Hopper Volume | 50L |
Total Power | 5Kw |
Overall Dimensions | 1000×900×2150mm or customized |
Operational Style | PLC control system,Colorful touch screen |
Production line diagram
1.Worker discharge the 5-50kg bag in the dust free bag dumping station, as there is a dust collector, so no dust fly
2.Vacuum conveyor transport the material into a mixer
3.After mixing, the mixed material will be conveyed into a packing machine by a screw feeder
