| Place of Origin: | China |
|---|---|
| Brand Name: | EVERSUN |
| Certification: | ISO, CE |
| Model Number: | NE |
| Minimum Order Quantity: | 1 set |
| Price: | negotiable |
| Packaging Details: | Standard export wooden box |
| Delivery Time: | within 7-15 work days |
| Payment Terms: | T/T, Western Union, MoneyGram, L/C |
| Supply Ability: | 5000SETS/YEAR |
| Bucket Volume: | 2.5-260L Or Customized | Bucket Speed: | 0.5m/s |
|---|---|---|---|
| Material Particle Size: | <120mm | Size: | Customized |
| Motor: | General Motor/ Explosion-proof Motor | Drive Type: | Chain Or Pulley Type |
| Application: | Grain, Seeds, Food, Etc | Capacity: | 15-470m3/h |
| High Light: | Wet Sand Chain Bucket Conveyor,SS304 Chain Bucket Elevator,Food Grade Carbon Steel Bucket Elevator |
||
| Model | Conveying capacity | Bucket speed | Spindle speed | Material particle size |
| m3/h | m/s | round/min | mm | |
| NE15 | 15 | 0.5 | 15.54 | <40 |
| NE30 | 32 | 16.45 | <50 | |
| NE50 | 60 | 16.45 | <50 | |
| NE100 | 110 | 14.13 | <70 | |
| NE150 | 170 | 14.13 | <70 | |
| NE200 | 210 | 10.9 | <100 | |
| NE300 | 320 | 10.9 | <100 | |
| NE400 | 380 | 8.3 | <120 | |
| NE500 | 470 | 7.1 | <120 |
The structural components of the Chain bucket elevator mainly include: elevator shell, elevator base, elevator head, elevator tail, transmission device (chain or pulley), bucket-shaped container, discharge port, feed port, etc. part.Among them, the elevator head is located at the top of the elevator, including the feed port, elevator head bearing, driving device, etc. The feed port is used to feed materials, and the driving device provides power through a chain or pulley to drive the movement of the bucket-shaped container.
Chain bucket elevators are widely used in various industries for lifting and transporting large quantities of materials in the vertical direction. They have high-efficiency transport capacity, space saving, flexible layout, suitability for a variety of materials, reliable stability and safety protection devices, etc. Advantages, suitable for grain processing, mining, chemical industry, building materials and other fields, providing fast, efficient and reliable material transportation solutions.
Choose EVERSUN's NEmodel for a high-capacity, durable, and efficient chain bucket elevator. Contact us now to learn more and get a quote!
At EVERSUN, we take great care in packaging and shipping our products to ensure they arrive at their destination in perfect condition.
Our Chain Bucket Elevators are carefully packaged to protect them from any potential damage during transportation. Each elevator is first wrapped in protective materials and then placed in a sturdy wooden crate or box. This packaging method ensures that the elevator is secure and well-protected throughout the shipping process.
We offer various shipping options to accommodate our customers' needs and preferences. Our standard shipping method is by sea, which allows for cost-effective and efficient delivery. However, we also offer air freight and land transportation for faster delivery, at an additional cost.
